OEM:
ZB4566 KNORR BREMSECojali reference:
2310913| Cartridge metric | M39x1,5 |
| Circuit 1 opening pressure | 108.78 psi (by-pass) |
| Circuit 3 opening pressure | 108.78 psi |
| Circuit 4 opening pressure | 108.78 psi |
| Circuit limitation pressure 3 | 123.28 psi |
| Circuit limitation pressure 4 | 123.28 psi |
| Connection 1 of the circuit protection | M16x1,5 |
| Connection 1 of the dryer | M22x1,5 |
| Connection 12 of the dryer | M22x1,5 |
| Connection 21 of the circuit protection | M16x1,5 |
| Connection 21 of the dryer | M16x1,5 |
| Connection 22 of the circuit protection | M16x1,5 |
| Connection 23 of the circuit protection | M16x1,5 |
| Connection 23 of the dryer | M16x1,5 |
| Connection 24 of the circuit protection | M16x1,5 |
| Connection 24 of the dryer | M22x1,5 |
| Connection 25 of the dryer | M16x1,5 |
| Connection 26 of the circuit protection | M22x1,5 |
| Cut-out pressure | 152.29 psi |
| Heater type | Bayoneta DIN 72585 A1-2 |
| Heater voltage | 24 V |
| OEM Reference of the circuit protection | AE4502 |
| OEM Reference of the dryer | LA 8124 |
| Presión apertura del circuito 2 | 108.78 psi (by-pass) |
| Reference of the circuit protection | 2322501 |
| Reference of the dryer | 2310538 |
| Safety device | Sí |
| SILENCER | No |
| Weight | 11.42 lb |
| Manufacturer | OEM Reference | Main OEM |
|---|---|---|
| KNORR BREMSE | ZB4566 | |
| KNORR BREMSE | II40542F | - |
| Cojali Reference | Name | OEM |
|---|
| Cojali Reference | Name | Obtained by | OEM |
|---|
