AIR DRYER

Name: AIR DRYER
Brand: Cojali
SKU: LA9011
Rating: 4.24 (18 reviews)

AIR DRYER

OEM:

LA9011 KNORR BREMSE

Cojali reference:

2310804 QUANTITY

Repair kits

TECHNICAL DATA

Cartridge metric	M39x1,5
Connection 11	M22x1,5
Connection 12	M12x1,5 (Taponada)
Connection 21	Sin rosca
Connection 22	M16x1,5
Connection 23	Inflador
Connection 24	M22x1,5 (Taponada)
Connection 25	M10x1 (Taponada)
Cut-out pressure	12,3 bar
Heater type	Bayoneta DIN 72585 A1-2
Heater voltage	24 V
SILENCER	No
Weight	2104.00 g

APPLICATIONS

Vehicle type	Brand	Series	Type	Model	Engine type
TRUCK	MERCEDES BENZ	---------	---------	---------	---------

CROSS-REFERENCING

Manufacturer	OEM Reference	Main OEM
KNORR BREMSE	LA9011
KNORR BREMSE	II38309F	-
KNORR BREMSE	II38309F170	-
KNORR BREMSE	II38309FN00	-
MERCEDES BENZ	0024311315	-
MERCEDES BENZ	A0024311315	-

RELATED PRODUCTS

	Cojali Reference	Name	OEM

REPAIR KITS

	Cojali Reference	Name	Obtained by	OEM
