OEM:
II38749FN50 KNORR BREMSECojali reference:
2322511| Circuit limitation pressure 3 | 120.38 psi |
| Circuit opening pressure 1 | 101.53 psi (by-pass) |
| Circuit opening pressure 2 | 101.53 psi (by-pass) |
| Circuit opening pressure 3 | 108.78 psi |
| Circuit opening pressure 4 | 101.53 psi |
| Connection 1 | M16x1,5 |
| Connection 11 | M22x1,5 VOSS |
| Connection 21 | M22x1,5 VOSS |
| Connection 22 | M22x1,5 VOSS |
| Connection 23 | M22x1,5 VOSS |
| Connection 24 | M22x1,5 VOSS |
| Connection 25 | M22x1,5 VOSS |
| Connection 26 | M22x1,5 VOSS |
| Electrical connection | Bayoneta DIN 72585 A1-6 |
| Safety device | Si |
| Voltage | 5 V |
| Weight | 4.9 lb |
| Vehicle type | Brand | Series | Type | Model | Engine type |
|---|---|---|---|---|---|
| TRUCK | DAF | --------- | --------- | --------- | --------- |
| Manufacturer | OEM Reference | Main OEM |
|---|---|---|
| DAF | 1612055 | - |
| DAF | 1607417 | - |
| KNORR BREMSE | II38749FN50 | |
| KNORR BREMSE | II38749F004 | - |
| KNORR BREMSE | AE4529 | - |
| KNORR BREMSE | II38749F | - |
| KNORR BREMSE | II38749F0041 | - |
| KNORR BREMSE | II38749F0042 | - |
| KNORR BREMSE | II38749FN00 | - |
| KNORR BREMSE | II38749FN52 | - |
| LEYLAND DAF | 1612055 | - |
| LEYLAND DAF | 1607417 | - |
| PACCAR | 1612055 | - |
| Cojali Reference | Name | Obtained by | OEM |
|---|
