United States
OEM:
AE4528 KNORR BREMSECojali reference:
2322504| Circuit 1 opening pressure | 101.53 psi (by-pass) |
| Circuit 3 opening pressure | 108.78 psi |
| Circuit 4 opening pressure | 101.53 psi (by-pass) |
| Circuit limitation pressure 3 | 123.28 psi |
| Connection 1 | M16x1,5 |
| Connection 21 | M22x1,5 VOSS |
| Connection 22 | M22x1,5 VOSS |
| Connection 23 | M22x1,5 VOSS |
| Connection 24 | M22x1,5 VOSS |
| Connection 25 | M22x1,5 VOSS |
| Connection 26 | M22x1,5 VOSS |
| Electrical connection | Bayoneta DIN 72585 A1-6 |
| Presión apertura del circuito 2 | 101.53 psi (by-pass) |
| Safety device | Si |
| Voltage | 5 V |
| Weight | 4.49 lb |
| Vehicle type | Brand | Series | Type | Model | Engine type |
|---|---|---|---|---|---|
| TRUCK | DAF | --------- | --------- | --------- | --------- |
| Manufacturer | OEM Reference | Main OEM |
|---|---|---|
| DAF | 1607416 | - |
| DAF | 1612054 | - |
| KNORR BREMSE | AE4528 | |
| KNORR BREMSE | II37464004 | - |
| KNORR BREMSE | II37464N50 | - |
| KNORR BREMSE | II37464 | - |
| KNORR BREMSE | II374640042 | - |
| KNORR BREMSE | II37464N00 | - |
| KNORR BREMSE | II37464N52 | - |
| LEYLAND DAF | 1612054 | - |
| LEYLAND DAF | 1607416 | - |
| PACCAR | 1612054 | - |
| Cojali Reference | Name | OEM |
|---|
| Cojali Reference | Name | Obtained by | OEM |
|---|
