4-WAY PROTECTION VALVE

Name: 4-WAY PROTECTION VALVE
Brand: Cojali
SKU: AE4180
Rating: 4.29 (21 reviews)

4-WAY PROTECTION VALVE

OEM:

AE4180 KNORR BREMSE

Cojali reference:

2322309 QUANTITY

Technical sheet

Repair kits

Add to the basket

TECHNICAL DATA

Technical sheet

Circuit opening pressure 1	7,0 bar
Circuit opening pressure 2	7,0 bar
Circuit opening pressure 3	7,0 bar
Circuit opening pressure 4	7,0 bar
Connection 1	M22x1,5
Connection 21	M16x1,5
Connection 22	M16x1,5
Connection 23	M16x1,5
Connection 24	M16x1,5
Safety device	No
Weight	889.50 g

APPLICATIONS

Vehicle type	Brand	Series	Type	Model	Engine type
BUS	IRISBUS	---------	---------	---------	---------

CROSS-REFERENCING

Manufacturer	OEM Reference	Main OEM
KNORR BREMSE	AE4180
KNORR BREMSE	I81192	-

REPAIR KITS

	Cojali Reference	Name	Obtained by	OEM
