4-WAY PROTECTION VALVE

4-WAY PROTECTION VALVE, 2222415, 9347140190
Home Online Catalogue Brake and suspension systems components 4-WAY PROTECTION VALVE

4-WAY PROTECTION VALVE

OEM:

9347140190 WABCO

Cojali reference:

2222415

DESCRIPTION

Valve that distributes air between the different pneumatic circuits and isolates affected sectors in case of leakage, improving the safety of the overall system.

TECHNICAL DATA

Technical sheet Technical sheet
Circuit 1 opening pressure 108.78 psi
Circuit 2 opening pressure 108.78 psi
Circuit 3 opening pressure 108.78 psi
Circuit 4 opening pressure 108.78 psi
Connection 1 M22x1,5
Connection 21 M16x1,5
Connection 22 M16x1,5
Connection 23 M16x1,5
Connection 24 M16x1,5
Safety device No
Weight 27.92 oz

APPLICATIONS

Vehicle type Brand Series Type Model Engine type
TRUCK DAF --------- --------- --------- ---------
TRUCK IVECO --------- --------- --------- ---------
BUS VDL BUS --------- --------- --------- ---------
TRUCK IVECO --------- --------- EUROTECH MT ---------
TRUCK IVECO --------- 60 E 10 EUROCARGO I-III ---------
TRUCK IVECO --------- 60 E 12 EUROCARGO I-III ---------
TRUCK IVECO --------- 60 E 14 K EUROCARGO I-III ---------
TRUCK IVECO --------- 65 E 10 EUROCARGO I-III ---------
TRUCK IVECO --------- 65 E 10 K EUROCARGO I-III ---------
TRUCK IVECO --------- 65 E 12, 65 E 12 P EUROCARGO I-III ---------
TRUCK IVECO --------- 65 E 12 K EUROCARGO I-III ---------
TRUCK IVECO --------- 65 E 14, 65 E 14 P EUROCARGO I-III ---------
TRUCK IVECO --------- 65 E 14 K EUROCARGO I-III ---------
TRUCK IVECO --------- 75 E 12, 75 E 12 P EUROCARGO I-III ---------
TRUCK IVECO --------- 75 E 12 K EUROCARGO I-III ---------
TRUCK IVECO --------- 75 E 14, 75 E 14 P EUROCARGO I-III ---------
TRUCK IVECO --------- 75 E 14 K EUROCARGO I-III ---------
TRUCK IVECO --------- 75 E 15, 75 E 15 P, 80 E 15 EUROCARGO I-III ---------
TRUCK IVECO --------- 75 E 15 K EUROCARGO I-III ---------
TRUCK IVECO --------- 80 E 15, 80 E 15 P EUROCARGO I-III ---------
TRUCK IVECO --------- 80 E 15 K EUROCARGO I-III ---------
TRUCK IVECO --------- 80 E 15 K EUROCARGO I-III ---------
TRUCK IVECO --------- 80 E 18 K EUROCARGO I-III ---------
TRUCK IVECO --------- 80 E 18 K EUROCARGO I-III ---------
TRUCK IVECO --------- 80 E 21, 80 E 21 P, 80 E 21 FP EUROCARGO I-III ---------
TRUCK IVECO --------- 80 E 21, 80 E 21 P, 21 E 80 FP EUROCARGO I-III ---------
TRUCK IVECO --------- 180 E 21 T EUROCARGO I-III ---------
TRUCK IVECO --------- 100 E 15, 100 E 15 P EUROCARGO I-III ---------
TRUCK IVECO --------- 100 E 15 K EUROCARGO I-III ---------
TRUCK IVECO --------- 100 E 18, 100 E 18 P EUROCARGO I-III ---------
TRUCK IVECO --------- 100 E 18 K EUROCARGO I-III ---------
TRUCK IVECO --------- 100 E 21, 100 E 21 P EUROCARGO I-III ---------
TRUCK IVECO --------- 120 E 15 EUROCARGO I-III ---------
TRUCK IVECO --------- 120 E 15 K EUROCARGO I-III ---------
TRUCK IVECO --------- 120 E 18, 120 E 18 P, 120 E 18 H EUROCARGO I-III ---------
TRUCK IVECO --------- 120 E 18 K EUROCARGO I-III ---------
TRUCK IVECO --------- 120 E 23,120 E 23 P, 120 E 23 FP, 120 E 23 H EUROCARGO I-III ---------
TRUCK IVECO --------- 130 E 15 EUROCARGO I-III ---------
TRUCK IVECO --------- 130 E 15 K EUROCARGO I-III ---------
TRUCK IVECO --------- 130 E 18 EUROCARGO I-III ---------
TRUCK IVECO --------- 130 E 18 K EUROCARGO I-III ---------
TRUCK IVECO --------- 135 E 18 WR EUROCARGO I-III ---------
TRUCK IVECO --------- 135 E 18 W EUROCARGO I-III ---------
TRUCK IVECO --------- 135 E 23 WR EUROCARGO I-III ---------
TRUCK IVECO --------- 135 E 23 W EUROCARGO I-III ---------
TRUCK IVECO --------- 150 E 15 EUROCARGO I-III ---------
TRUCK IVECO --------- 150 E 15 K EUROCARGO I-III ---------
TRUCK IVECO --------- 150 E 18, 150 E 18 P EUROCARGO I-III ---------
TRUCK IVECO --------- 150 E 18 K EUROCARGO I-III ---------
TRUCK IVECO --------- 150 E 23, 150 E 23 P, 150 E 23 FP EUROCARGO I-III ---------
TRUCK IVECO --------- 150 E 27, 150 E 27 P, 150 E27FP, 150 E 27 R EUROCARGO I-III ---------
TRUCK IVECO --------- 170 E 18, 180 E 18 EUROCARGO I-III ---------
TRUCK IVECO --------- 170 E 18 K, 180 E 18 K EUROCARGO I-III ---------
TRUCK IVECO --------- 170 E 23,180 E 23 EUROCARGO I-III ---------
TRUCK IVECO --------- 170 E 23 K,180 E 23 K EUROCARGO I-III ---------
TRUCK IVECO --------- 170 E 27,180 E 27 EUROCARGO I-III ---------
TRUCK IVECO --------- 260 E 23 T EUROCARGO I-III ---------
TRUCK IVECO --------- 280 E 23 T EUROCARGO I-III ---------
TRUCK IVECO --------- 320 E 27 T EUROCARGO I-III ---------
TRUCK IVECO --------- 95 E 15 W EUROCARGO I-III ---------
TRUCK IVECO --------- 95 E 21 W EUROCARGO I-III ---------
TRUCK IVECO --------- MP 190 E 30 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 190 E 30 W EUROTRAKKER ---------
TRUCK IVECO --------- MP 190 E 34 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 190 E 34 W EUROTRAKKER ---------
TRUCK IVECO --------- MP 190 E 37 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 190 E 37 W EUROTRAKKER ---------
TRUCK IVECO --------- MP 190 E 42 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 190 E 42 W EUROTRAKKER ---------
TRUCK IVECO --------- MP 400 E 34 HT EUROTRAKKER ---------
TRUCK IVECO --------- MP 400 E 37 HT EUROTRAKKER ---------
TRUCK IVECO --------- MP 400 E 37 WT EUROTRAKKER ---------
TRUCK IVECO --------- MP 400 E 42 HT EUROTRAKKER ---------
TRUCK IVECO --------- MP 400 E 42 WT EUROTRAKKER ---------
TRUCK IVECO --------- MP 260 E 30 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 260 E 34 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 260 E 34 W EUROTRAKKER ---------
TRUCK IVECO --------- MP 260 E 37 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 260 E 37 W EUROTRAKKER ---------
TRUCK IVECO --------- MP 260 E 42 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 260 E 42 W EUROTRAKKER ---------
TRUCK IVECO --------- MP 440 E 34 HT EUROTRAKKER ---------
TRUCK IVECO --------- MP 440 E 37 HT EUROTRAKKER ---------
TRUCK IVECO --------- MP 440 E 42 HT EUROTRAKKER ---------
TRUCK IVECO --------- MP 340 E 34 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 340 E 37 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 380 E 37 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 380 E 37 W EUROTRAKKER ---------
TRUCK IVECO --------- MP 380 E 34 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 380 E 42 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 380 E 42 W EUROTRAKKER ---------
TRUCK IVECO --------- MP 720 E 37 HT EUROTRAKKER ---------
TRUCK IVECO --------- MP 720 E 37 WT EUROTRAKKER ---------
TRUCK IVECO --------- MP 720 E 42 HT EUROTRAKKER ---------
TRUCK IVECO --------- MP 720 E 42 WT EUROTRAKKER ---------
TRUCK IVECO --------- MP 410 E 37 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 410 E 42 H EUROTRAKKER ---------
TRUCK IVECO --------- MP 410 E 42 W EUROTRAKKER ---------

CROSS-REFERENCING

Manufacturer OEM Reference Main OEM
DAF 1519213 -
IVECO 9841 3416 -
IVECO 161507 -
IVECO 42544391 -
IVECO 98400429 -
IVECO 99480157 -
MAGNETI MARELLI VPS 45 A -
VDL BUS 20252278 -
WABCO 9347140190

REPAIR KITS

  Cojali Reference Name Obtained by OEM
