OEM:
9347050210 WABCOCojali reference:
2222308| Circuit limitation pressure 3 | 123.28 psi |
| Circuit limitation pressure 4 | 123.28 psi |
| Circuit opening pressure 1 | 108.78 psi |
| Circuit opening pressure 2 | 108.78 psi |
| Circuit opening pressure 3 | 78.32 psi + 108.78 psi |
| Circuit opening pressure 4 | 108.78 psi |
| Connection 1 | M22x1,5 VOSS |
| Connection 21 | M16x1,5 |
| Connection 22 | M16x1,5 |
| Connection 23 | M16x1,5 |
| Connection 24 | M16x1,5 |
| Connection 26 | M22x1,5 VOSS |
| Electrical connection | Bayoneta DIN 72585 A1-6 |
| Safety device | Si |
| Voltage | 5 V |
| Weight | 4.07 lb |
| Vehicle type | Brand | Series | Type | Model | Engine type |
|---|---|---|---|---|---|
| TRUCK | IVECO | --------- | --------- | --------- | --------- |
| Manufacturer | OEM Reference | Main OEM |
|---|---|---|
| WABCO | 9347050210 |
| Cojali Reference | Name | Obtained by | OEM |
|---|
