OEM:
9347050080 WABCOCojali reference:
2222304| Circuit limitation pressure 1 | 10,0 bar |
| Circuit limitation pressure 2 | 10,0 bar |
| Circuit limitation pressure 3 | 8,6 bar |
| Circuit limitation pressure 4 | 8,6 bar |
| Circuit opening pressure 1 | 9,0 bar (by-pass) |
| Circuit opening pressure 2 | 9,0 bar (by-pass) |
| Circuit opening pressure 3 | 7,5 bar |
| Circuit opening pressure 4 | 7,5 bar |
| Connection 1 | M22x1,5 VOSS |
| Connection 21 | M22x1,5 VOSS |
| Connection 22 | M22x1,5 VOSS |
| Connection 23 | M22x1,5 VOSS |
| Connection 24 | M22x1,5 VOSS |
| Connection 25 | M22x1,5 VOSS |
| Connection 26 | M22x1,5 VOSS |
| Connection 27 | M12x1,5 |
| Connection 28 | M12x1,5 |
| Electrical connection | Bayoneta DIN 72585 A1-6 |
| Safety device | Si |
| Voltage | 24 V |
| Weight | 2055.00 g |
| Vehicle type | Brand | Series | Type | Model | Engine type |
|---|---|---|---|---|---|
| TRUCK | MERCEDES BENZ | --------- | --------- | --------- | --------- |
| BUS | EVOBUS | --------- | --------- | --------- | --------- |
| Manufacturer | OEM Reference | Main OEM |
|---|---|---|
| WABCO | 9347050080 |
| Cojali Reference | Name | OEM |
|---|
| Cojali Reference | Name | Obtained by | OEM |
|---|
