OEM:
9325000990 WABCOCojali reference:
2210627| Cartridge metric | M39x1,5 |
| Circuit 1 opening pressure | 94.27 psi |
| Circuit 3 opening pressure | 108.78 psi |
| Circuit 4 opening pressure | 94.27 psi |
| Connection 1 of the circuit protection | Sin rosca |
| Connection 1 of the dryer | M22x1,5 |
| Connection 21 of the circuit protection | M16x1,5 |
| Connection 21 of the dryer | M22x1,5 |
| Connection 22 of the circuit protection | M16x1,5 |
| Connection 23 of the circuit protection | M16x1,5 |
| Connection 24 of the circuit protection | M16x1,5 |
| Connection 4/23 of the dryer | M12x1,5 (Taponada) |
| Cut-out pressure | 123.28 psi |
| Heater type | Bayoneta DIN 72585 A1-2 |
| Heater voltage | 24 V |
| OEM Reference of the circuit protection | 934 714 151 0 |
| OEM Reference of the dryer | 432 415 066 0 |
| Presión apertura del circuito 2 | 94.27 psi |
| Reference of the circuit protection | 2222441 |
| Reference of the dryer | 2210249 |
| Safety device | No |
| SILENCER | Si (2203100) |
| Weight | 7.29 lb |
| Manufacturer | OEM Reference | Main OEM |
|---|---|---|
| WABCO | 9325000990 |
| Cojali Reference | Name | OEM |
|---|
