OEM:
9325000400 WABCOCojali reference:
2210638| Cartridge metric | M39x1,5 |
| Circuit 1 opening pressure | 130.53 psi (by-pass) |
| Circuit 3 opening pressure | 108.78 psi |
| Circuit 4 opening pressure | 108.78 psi |
| Circuit limitation pressure 1 | 145.04 psi |
| Circuit limitation pressure 2 | 145.04 psi |
| Circuit limitation pressure 3 | 123.28 psi |
| Circuit limitation pressure 4 | 123.28 psi |
| Connection 1 of the circuit protection | M22x1,5 VOSS |
| Connection 11 of the dryer | M22x1,5 |
| Connection 12 of the dryer | M12x1,5 |
| Connection 21 of the circuit protection | M22x1,5 VOSS |
| Connection 21 of the dryer | M22x1,5 |
| Connection 22 of the circuit protection | M22x1,5 VOSS |
| Connection 22 of the dryer | M16x1,5 |
| Connection 23 of the circuit protection | M22x1,5 VOSS |
| Connection 23 of the dryer | Inflador |
| Connection 24 of the circuit protection | M22x1,5 VOSS |
| Connection 24 of the dryer | M22x1,5 |
| Connection 25 of the circuit protection | M22x1,5 VOSS |
| Connection 26 of the circuit protection | M22x1,5 VOSS |
| Connection 27 of the circuit protection | M12x1,5 |
| Connection 28 of the circuit protection | M12x1,5 |
| Connection 4/25 of the dryer | M10x1 |
| Cut-out pressure | 174.05 psi |
| Heater type | Bayoneta DIN 72585 A1-2 |
| Heater voltage | 24 V |
| OEM Reference of the circuit protection | 934 705 005 0 |
| OEM Reference of the dryer | 932 400 018 0 |
| Presión apertura del circuito 2 | 130.53 psi (by-pass) |
| Pressure sensor connector | Bayoneta DIN 72585 A1-6 |
| Pressure sensor voltage | 5V |
| Reference of the circuit protection | 2222303 |
| Reference of the dryer | 2210507 |
| Safety device | Sí |
| SILENCER | No |
| Weight | 8.34 lb |
| Vehicle type | Brand | Series | Type | Model | Engine type |
|---|---|---|---|---|---|
| TRUCK | MERCEDES-BENZ | --------- | --------- | --------- | --------- |
| BUS | EVOBUS | --------- | --------- | --------- | --------- |
| Manufacturer | OEM Reference | Main OEM |
|---|---|---|
| WABCO | 9325000400 |
| Cojali Reference | Name | OEM |
|---|
| Cojali Reference | Name | Obtained by | OEM |
|---|
