Spain
OEM:
9325000060 WABCOCojali reference:
2210603| Cartridge metric | M39x1,5 |
| Circuit 1 opening pressure | 9,0 bar (by-pass) |
| Circuit 3 opening pressure | 7,5 bar |
| Circuit 4 opening pressure | 7,5 bar |
| Circuit limitation pressure 1 | 10,0 bar |
| Circuit limitation pressure 2 | 10,0 bar |
| Circuit limitation pressure 3 | 8,5 bar |
| Circuit limitation pressure 4 | 8,5 bar |
| Connection 1 of the circuit protection | M22x1,5 VOSS |
| Connection 11 of the dryer | M22x1,5 |
| Connection 12 of the dryer | M12x1,5 |
| Connection 21 of the circuit protection | M22x1,5 VOSS |
| Connection 21 of the dryer | M22x1,5 |
| Connection 22 of the circuit protection | M22x1,5 VOSS |
| Connection 22 of the dryer | M16x1,5 |
| Connection 23 of the circuit protection | M22x1,5 VOSS |
| Connection 23 of the dryer | Inflador |
| Connection 24 of the circuit protection | M22x1,5 VOSS |
| Connection 24 of the dryer | M22x1,5 |
| Connection 25 of the circuit protection | M22x1,5 VOSS |
| Connection 26 of the circuit protection | M22x1,5 VOSS |
| Connection 27 of the circuit protection | M12x1,5 |
| Connection 28 of the circuit protection | M12x1,5 |
| Connection 4/25 of the dryer | M10x1 (Taponada) |
| Cut-out pressure | 12,0 bar |
| OEM Reference of the circuit protection | 934 705 005 0 |
| OEM Reference of the dryer | 932 400 001 0 |
| Presión apertura del circuito 2 | 9,0 bar (by-pass) |
| Pressure sensor connector | Bayoneta DIN 72585 A1-6 |
| Pressure sensor voltage | 5V |
| Reference of the circuit protection | 2222303 |
| Reference of the dryer | 2210500 |
| Safety device | Sí |
| SILENCER | No |
| Weight | 3745.50 g |
| Vehicle type | Brand | Series | Type | Model | Engine type |
|---|---|---|---|---|---|
| TRUCK | MERCEDES BENZ | --------- | --------- | --------- | --------- |
| BUS | EVOBUS | --------- | --------- | --------- | --------- |
| Manufacturer | OEM Reference | Main OEM |
|---|---|---|
| MERCEDES BENZ | 001 431 78 15 | - |
| MERCEDES BENZ | 001 431 81 15 | - |
| MERCEDES BENZ | A0014318115 | - |
| MERCEDES BENZ | 0014316415 | - |
| MERCEDES BENZ | 0014316715 | - |
| MERCEDES BENZ | A0014316415 | - |
| MERCEDES BENZ | A0014316715 | - |
| MERCEDES BENZ | A0014317815 | - |
| WABCO | 9325000060 |
| Cojali Reference | Name | OEM |
|---|
| Cojali Reference | Name | Obtained by | OEM |
|---|
